108-38-3

間二甲苯(108-38-3)紅外圖譜(IR1)

產(chǎn)品名稱:間二甲苯

CAS:108-38-3

分子式:C8H10

分子量: 106.17

InChI:InChI=1S/C8H10/c1-7-4-3-5-8(2)6-7/h3-6H,1-2H3

InChIKey: IVSZLXZYQVIEFR-UHFFFAOYSA-N

Smiles:C1(C)=CC=CC(C)=C1

  • 圖譜
    Mass

    MS-NW-0045
m-xylene
C8H10               (Mass of molecular ion:    106)


       Source Temperature: 222 °C
   Sample Temperature:  55 °C
   Reservoir, 75 eV


          27.0       2.7
      28.0       1.3
      38.0       1.2
      39.0       7.7
      41.0       1.2
      50.0       2.7
      51.0       7.5
      52.0       3.4
      53.0       2.1
      62.0       1.6
      63.0       4.7
      65.0       6.0
      74.0       1.1
      77.0      11.3
      78.0       5.6
      79.0       7.1
      89.0       1.9
      91.0     100.0
      92.0       7.6
     102.0       1.1
     103.0       6.0
     104.0       2.6
     105.0      28.8
     106.0      71.0
     107.0       6.2

400 MHz in CDCl3

  • 圖譜

    1H NMR 399.65 MHz
    C8 H10 0.05 ml : 0.5 ml CDCl3
    m-xylene
    ChemicalStructure
        Assign.     Shift(ppm)

      A             7.109
      B             6.96
      C             6.94
      D             2.278


         Hz     ppm     Int.


       2849.49   7.130     58
   2841.80   7.111    125
   2834.47   7.093     81
   2783.33   6.965     52
   2781.25   6.960    122
   2780.64   6.958    141
   2779.91   6.956    146
   2779.17   6.955    146
   2778.44   6.953    165
   2777.83   6.951    192
   2777.22   6.950    203
   2776.61   6.948    187
   2769.90   6.931    140
   2769.41   6.930    147
   2768.68   6.928    139
   2768.07   6.927    120
    910.64   2.279   1000
    910.28   2.278    994

in CDCl3

  • 圖譜

liquid film

  • 圖譜

4880 A,200 M,liquid

  • 圖譜

ANION RADICAL, REDUCTION WITH NA OR K IN DME

  • 圖譜

×
